6-Ports, X-Pol, Panel Antenna, 2.0m, 2x 690-960/1x 1695-2690MHz, 65deg, Integrated RET
Rev : E | Rev date : 20 Feb 2023
FEATURES / BENEFITS
- 4 ports / 2 cross pol systems in low band (690-960 MHz)
- 2 ports / 1 cross pol system in very wide high band (1695-2690 MHz)
- Integrated and field replaceable SRET
- ACU HW Version -HRLS200608H1.00
- Compliant with AISG V2.0 and 3GPP
External Document Links
- All electrical parameters are compliant with BASTA NGMN 11.1 requirements.
- For additional mounting information please click "External Document Links".
- Radiating patterns: Request pattern files
