HA-AD-SASA-40
Hybriflex Adapter, SC/APC Simplex

Rev : A | Rev date : 17 Jan 2022

A high precision simplex SC/APC adapter with standard housing. Designed to provide low insertion loss, high return loss and excellent stability for RoF (Radio over Fibre) applications.

FEATURES / BENEFITS

  • Low insertion loss
  • End face polish: PC, UPC,APC
  • Durability 500 times
  • Available in PVC, LSZH etc for cable sheath
  • Meet standard IEC61754
  • Comply with ROHS


Technical features

Mechanical Specifications

MaterialPolyetherimide

Testing and Environmental

Operation Temperature °C (°F)-40 to 85 (-40 to 185 )

F/O Cable Specifications

Insertion Loss≤ 0.2dB
Repeatatability / durability≤ 0.2dB for 500 mate/de-mate cycles
StandardIEC 61754-20
