TRIM-LCF114-D01-A
Automated trimming tool, LCF 114, LCFS114, OMNI FIT Premium, Trim Series D01


Special trimming tool makes the OMNI FIT Premium D01 connector attachment easier. No further tools are required to prepare the cable for the connector attachment. This is due to the unique design of the trimming tool, which combines all necessary functions in one compact tool. It can be used for CELLFLEX® LCFS114-50 and UCF114-50 foam dielectric cables.

FEATURES / BENEFITS

  • Precision cable preparation tool
    Always exact and repeatable trimming dimensions
  • Intuitive use of tool
    Easy and precise preparation of cables for connector installation
  • Long-lasting cutting blades
    Low maintenance costs
  • Battery drill drive compatible
    Increased preparation speed


TRIM-LCF114-D01-A

Technical features

Structure

Product LineCoaxial Cable Accessories
Product TypeTool
Transmission Line TypeLCFS114, UCF114
Coaxial Cable TypeFoam Dielectric
Cable Size1-1/4"
Type of ToolAutomated Cable Trimming Tool

Accessories

Spare Part / Useful AccessoriesSpare blades, Main blade : TRIM-B17
Jacket blade : TRIM-B18

Mechanical Specifications

MaterialAluminium

Packaging Information

Package Quantity1
Weight per piece kg (lb)0.84 (1.9)
