I-ATO5-698/3800
Indoor Omnidirectional Antenna 698-3800 MHz

Rev : A | Rev date : 09 May 2019

The omnidirectional antenna I-ATO5-698/3800 is designed for broadband in-building DAS applications supporting all kind of safety as well as 4G and 5G commercial wireless communication networks. The antenna combines an aesthetical design with superior electrical characteristics notably a PIM optimized design to minimize network interferences. The antenna is constructed from lightweight materials ideal for easy ceiling mounting. The low profile and off-white radome blends easily into most building aesthetics with minimum visual impact.

FEATURES / BENEFITS

Wideband omni antenna, supporting all wireless services in the frequency bands 698-960/1427-2700MHz/3400-3800MHz
Typically used in indoor distribution of 2G / 3G / 4G / 5G wireless services in all standardized frequency bands
PIM optimized antenna design (-153dBc @2x20W)
Aesthetical visual appearance, compact and light weight
Low return loss, stable performance
Pigtail with N female connector
Ceiling mounting

I-ATO5-698/3800

Technical features

General Specifications
Product Type		Omnidirectional Antenna
Techn. Application		Indoor

Mechanical Specifications
Number of Input Ports		1
Connectors		N female
Connector Cable	mm (in)	300 (11.8)
Mounting Hardware included		mountig clamp
Height (Less Connectors)	mm (in)	115 (4.53)
Diameter (Less Connectors)	mm (in)	203 (8)
Weight	kg (lb)	0.37 (0.82)

Electrical Specifications
Frequenz	MHz	698-806	806-960	1427-1710	1710-2700	3400-4000
Gain, typ	dBi	1.8	2.0	3.0	3.0	4.5
VSWR		1.8	1.5	1.8	1.5	1.8
Impedance, Ohm	Ω	50
Polarization		Vertical
Intermodulation (IM3)		-153 dBc
Total Input Power max.	W	50
