- NMR-LCF14-D01
NMR-LCF14-D01
N Male Right Angle Connector for 1/4" Coaxial Cable, OMNI FIT™ Premium,
O-Ring and compression sealing
All RFS connectors are fully tested for mechanical and electrical compliance to industry specifications.
The N connector meets all technical requirements and covers high frequencies as well as legacy applications. Sealing against outer conductor and jacket by means of O-Ring and 360° compression fit. Multifunctional, self-lubricating HighTech polymer assembly locks on cable corrugation, avoids electrochemical potential differences and compression-fits to the jacket.;
FEATURES / BENEFITS
- Ultra high PIM performance i.e. reduced interference leading to high customer satisfaction
- Two-piece design i.e. visual inspection of interlocking leads to improved installation security
- OMNI FIT™ concept i.e. streamlined order management and reduced stock level
- Watertight sealing in mated and unmated condition, i.e. reduced efforts during installation and improved security during operation
- Unique NiTin plating i.e. extreme resistance against corrosion even under hardest climatic and environmental circumstances
- Multi-thread (Tristart) design i.e. simplified and accelerated tightening process
- RoHS (EU) and CRoHS (China) compliant i.e. can be used on a global basis
OMNI FIT™ Premium Connectors
Technical features
|
|
|
|
|
External Document Links
Notes
Related Products
RSB-S38/L14
RSB-Clip (incl. clamp lining)
- Hanger Type : RSB-Clip (incl. clamp lining)
- Cable Type : Superflexible Coaxial Foam Dielectric, Braid/Foil Shield, Coaxial Foam Dielectric
- Cable Size : 3/8
