LCF14-50J
1/4" CELLFLEX® Low loss Flexible Cable

CELLFLEX® 1/4" low loss flexible cable

FEATURES / BENEFITS

  • Low Attenuation
    The low attenuation of CELLFLEX® coaxial cable results in highly efficient signal transferin your RF system.
  • Complete Shielding
    The solid outer conductor of CELLFLEX® coaxial cable creates a continuous RFI/EMI shield that minimizes system interference.
  • Low VSWR
    Special low VSWR versions of CELLFLEX® coaxial cables contribute to low system noise.
  • Outstanding Intermodulation Performance
    CELLFLEX® coaxial cable�s solid inner and outer conductors virtually eliminate intermods. Intermodulation performance is also confirmed with state-of-the-art equipment at the RFS factory.
  • High Power Rating
    Due to their low attenuation, outstanding heat transfer properties and temperature stabilized dielectric
    materials, CELLFLEX® cable provides safe long term operating life at high transmit power levels.
  • Wide Range of Application
    Typical areas of application are: feedlines for broadcast and terrestrial microwave antennas, wireless cellular, PCS and ESMR base stations, cabling of antenna arrays, and radio equipment interconnects.


1/4" CELLFLEX® Superflexible Foam Dielectric Coaxial Cable

Technical features

Applications

ApplicationsOEM jumpers, BTS inter-cabinet connections, GPS lines, Microwave IF cabling, intended for outdoor usage

Structure

Cable TypeFoam-Dielectric, Corrugated
Size1/4
Jacket OptionBlack
Inner Conductormm (in)2.4 (0.09)
Inner Conductor MaterialCopper-Clad Aluminum Wire
Dielectricmm (in)6 (0.24)
Dielectric MaterialFoam Polyethylene
Outer Conductormm (in)7.5 (0.3)
Outer Conductor MaterialCorrugated Copper
Jacketmm (in)10 (0.39)
Jacket MaterialPolyethylene, PE

Testing and Environmental

Fire PerformanceHalogene Free
Installation Temperature °C(°F)-40 to 60 (-40 to 140)
Storage Temperature°C(°F)-70 to 85 (-94 to 185)
Operation Temperature °C(°F)-50 to 85 (-58 to 185)

Electrical Specifications

Impedance, OhmΩ50 +/- 1.5
Maximum Frequency GHz15.8
Velocity, percent%83
Capacitance pF/m (pF/ft)80 (24)
Inductance, uH/m (uH/ft)µH/m (µH/ft)0.205 (0.063)
Peak Power Rating kW10.9
RF Peak Voltage Volts1050
Jacket Spark Volt RMS5000
Inner Conductor dc Resistance, Ω/km (Ω/kft)Ω/1000 m (Ω/1000 ft)6.1 (1.86)
Outer Conductor dc Resistance, ohm/1000 m (Ohm/1000 ft)Ω/1000 m (Ω/1000 ft)4.4 (1.34)
Return Loss (VSWR) PerformanceStandard (for 40-2700, 3300-4200, 4400-5925 MHz) or Premium
Min. Return Loss (Max. VSWR)dB (VSWR)Standard 20 (1.222), Premium 24 (1.135)/ 23 (1.152)
Phase Stabilized

Phase stabilized and phase matched cables and assemblies are available upon request.

Temperature & PowerStandard

Mechanical Specifications

Cable Weight, Nominal kg/m (lb/ft)0.11 (0.074)
Minimum Bending Radius, Single Bendmm (in)40 (1.6)
Minimum Bending Radius, Repeated Bendsmm (in)85 (3.3)
Bending Moment, Nm (lb-ft)Nm (lb*ft)1.9 (1.4)
Tensile Strength N (lb)890 (200)
Recommended / Maximum Clamp Spacing m (ft)0.5 / 1 (1.75 / 3.25)

Attenuation @ 20°C (68°F) and Power Rating @ 40°C (104°F)

Frequency, MHzdB per 100mdB per 100ftPower, kW
0.5 0.29 0.09 10.90
1 0.41 0.13 10.90
1.5 0.51 0.15 10.90
2 0.58 0.18 10.90
10 1.31 0.40 5.56
20 1.86 0.57 3.92
30 2.28 0.70 3.20
50 2.95 0.90 2.47
88 3.94 1.20 1.85
100 4.20 1.28 1.73
108 4.37 1.33 1.67
150 5.17 1.58 1.41
174 5.58 1.70 1.30
200 6 1.83 1.21
300 7.40 2.25 0.99
400 8.59 2.62 0.85
450 9.13 2.78 0.80
500 9.65 2.94 0.76
512 9.77 2.98 0.75
600 10.60 3.24 0.69
700 11.50 3.51 0.63
800 12.40 3.77 0.59
824 12.60 3.83 0.58
894 13.10 4 0.56
900 13.20 4.01 0.55
925 13.40 4.07 0.55
960 13.60 4.15 0.54
1000 13.90 4.24 0.52
1250 15.70 4.78 0.46
1500 17.30 5.27 0.42
1700 18.50 5.64 0.39
1800 19.10 5.82 0.38
2000 20.20 6.16 0.36
2100 20.80 6.33 0.35
2200 21.30 6.49 0.34
2400 22.30 6.81 0.33
3000 25.30 7.70 0.29
3500 27.50 8.39 0.27
4000 29.70 9.05 0.25
5000 33.70 10.30 0.22
6000 37.40 11.40 0.20
7000 40.80 12.40 0.18
8000 44.10 13.50 0.17
9000 47.30 14.40 0.15
10000 50.30 15.30 0.15
12000 56.10 17.10 0.13
14000 61.50 18.80 0.12
15800 66.20 20.20 0.11

External Document Links

Notes

Phase stabilized versions available upon request.

Phase stabilized versions available upon request.
