RSB-300/380
RSB Clip with clamp lining for FLEXWELL® Elliptical Waveguide E300 and E380

Rev : C | Rev date : 07 Jun 2012
The RSB clip is designed for installation of FLEXWELL elliptical waveguide types E105 to E380 and overmoded waveguide type EO38. The clip is a universal clamp device which can be used in many mounting configurations.
The clip is manufactured from stainless steel and is resistant against most environmental conditions.
The set consists of a stainless steel clamp including a clamp lining made of rubber.

FEATURES / BENEFITS

Elliptical Waveguide installation

  • The RSB clip provides a simple and fast installation of small and medium size elliptical waveguides
  • It includes a rubber clamp lining


RSB_78_with_lining_E220_TI

External Document Links

Notes

Technical features

General Specifications

Product LineElliptical Waveguide Accessories
Product TypeHanger
Hanger TypeRSB Clip with clamp lining for Elliptical Waveguide
Transmission Line TypeE300
E380

Mechanical Specifications

Number of Cable / Waveguide Runs1
MaterialClamp: Stainless steel
Clamp lining: EPDM rubber
Drill Hole Size mm (in)8 (0.315)

Accessories

Spare Part / Useful AccessoriesCleat : RSB-310
Anchor bar fixation : RSB-315

Temperature Specifications

Operation Temperature °C (°F)-50 to 85 (-58 to 185 )
Storage Temperature °C (°F)-50 to 85 (-58 to 185 )

Packaging Information

Package Quantity10
