FDIE-C150
Flanging die for use with FLEXWELL® waveguide E150, compact tool

Brass made flanging die for use with FLEXWELL® waveguide E150, compact tool, abrasion resistant sawing jig

FEATURES / BENEFITS

Elliptical Waveguide installation
  • The flanging die in conjunction with the flanging tool simplifies the installation
  • The use of the tool guarantees a safe and proper installation of the Waveguide connector


Technical features

Structure

Product LineElliptical Waveguide Accessories
Product TypeFlanging Tool
Transmission Line TypeE150, EP150
Cable SizeSize C
Type of ToolFlanging Die
SizeSize C

Accessories

Required ToolBasic Compact Tool : FTOOL-C105380

Mechanical Specifications

MaterialAluminium / Brass
Length mm (in)165 (6.5)
Height mm (in)78 (3.07)
Width mm (in)78 (3.07)

Packaging Information

Package Quantity1
Weight per piece kg (lb)0.86 (1.9)

External Document Links

Notes

Applicable for connectors with IEC flanges
