CC200EUR
Inner Conductor Cleaner


This is an optional connector preparation tool for CELLFLEX® cables with solid inner conductor.
- It helps to remove the residual dielectric from the inner conductor of cables during the preparation
for connector installation.
- It enables clean contact areas without any risk of surface degradation.

FEATURES / BENEFITS

  • Enables clean contact surfaces without risk of scratching and nicking
  • Finger grippers permit application of sufficient force
  • Removes dielectric close to the cutting area
  • Helps to fulfil the electrical performance of connectors, especially PIM, more easily and consistently


CC200EUR

Technical features

Structure

Product LineCoaxial Cable Accessories
Product TypeTool
Transmission Line TypeAll cables with solid inner conductor
Coaxial Cable TypeFoam Dielectric
Cable SizeUp to and including 1/2"
Type of ToolCable Preparation Tool
ConfigurationInner Conductor Cleaner

Mechanical Specifications

ColorYellow
MaterialPlastic
Length mm (in)108 (4.25)

Packaging Information

Weight per piece kg (lb)0.06 (0.14)

External Document Links

Notes

Refer also to the Installation Instructions of the corresponding connector.
