MBHS114-3-F
Single Multi-block hanger, with angle member adapter


Single Multi block hanger support systems are designed for organizing bundled runs of coax cable.
Each space-saving block securely holds one run of coax, allowing a compact bundle of up to 3x runs to be supported by stacking three blocks.

FEATURES / BENEFITS

  • Single Multi Blocks are manufactured of polypropylene providing thermal, chemical and UV resistance in all environments.
  • They come including angle member adapter and necessary hardware.
  • The angle member adapter fastens the clamp to the tower without drilling.
  • The angle member adapter includes a tower member set screw.
  • The hanger mounting rod may be located in either of two mounting holes, depending on orientation of the fixing member.
  • Compliant to RoHS (EU 2002/95/EC) and CRoHS (China SJ/T11363-2006) i.e. usable on a global basis.


picture shows MBHS78-3-F for illustration purpose

Technical features

General Specifications

Product LineCoaxial Cable Accessories
Hybrid Cable Accessories
Product TypeHanger
Hanger TypeSingle Multi-block
Transmission Line TypeUCF114
LCFS114
LCF114
HB114
Cable TypeCoaxial Foam Dielectric
Hybrid
ColorBlack

Mechanical Specifications

Cable Size1-1/4
Number of Cable / Waveguide Runs1 per layer, 3 layers, 3 runs
Configurationincl. Angle member adapter
Angle member adapter clamping range mm (in)4 / 24 (0.157 / 0.945 )
Angle member adpter threads2x M8
MaterialMetal part: Stainless steel
Plastic parts: Polypropylene
Length mm (in)290 (11.4) see picture below (L)
Height mm (in)80 (3.15) see picture below (H)
Width mm (in)50 (1.96) see picture below (W)
Recommended / Maximum Clamp Spacing m (ft)0.9 / 1.2 (2.95 / 4)

Temperature Specifications

Operation Temperature °C (°F)-50 to 85 (-58 to 185 )
Storage Temperature °C (°F)-50 to 85 (-58 to 185 )

Packaging Information

Package Quantity10
Weight per piece kg (lb)0.35 (0.77)
Weight per kit kg (lb)3.7 (8.15)
Box Dimensions (Bulk Shipping), L x W x Hmm (in)230 x 155 x 335 (9.0 x 6.1 x 13.1)


picture shows MBHS78-3-F for illustration purpose

External Document Links

Notes

For applications under wind speed conditions from 160 km/h (100 mph) up to 200 km/h (125 mph) a maximum clamp spacing of 0.7m (2.3 ft) must not be exceeded.
